Cylindrical Expanding Mandrel – Technical Specifications
Parameter | Value |
Expansion range | Φ160 – Φ3500 mm |
Winding length | Max. 4000 mm |
Parallelism tolerance | ± 2.0 mm |
Roundness tolerance | ± 2.0 mm |
Adjusting method | Manual, electric & pneumatic |
Usage | Vertical and horizontal dual-use |
Cylindrical mandrel supporting both vertical and horizontal winding orientations. Variable diameter design allows one tool to cover multiple coil sizes, reducing changeover time and tooling inventory.
Detailed Description
Overview
This cylindrical adjustable winding mandrel is engineered for flexibility and efficiency. Its vertical and horizontal dual-use capability means you can mount it on different winding machines without changing tooling. The variable diameter mechanism enables quick size adjustment, making it ideal for prototype development and small-batch production.
Key Features
Dual orientation – Works in both vertical and horizontal winding positions
Variable diameter – Quickly adjust to different coil inner diameters
Rigid construction – Maintains accuracy under winding tension
Compatible design – Fits standard winding machine shafts
Benefits
One mandrel replaces multiple fixed-size mandrels
Minimizes setup time between production runs
Reduces storage space for tooling
Lowers overall tooling costs
Typical Applications
Cylindrical transformer coils
Electromagnetic coils
Inductor coils
Motor field coils
Solenoid coils
Compatibility
Fits most standard winding machines. Custom shaft adapters available upon request.
Parameter | Value |
|
Diameter adjustment range | 50mm – 300mm | Customizable upon request |
Max winding tension | 500N |
Compatible shaft diameter | 25mm / 32mm / 40mm |
Material | Aluminum alloy / Carbon steel |
Adjustment mechanism | Manual screw / Quick-release |
Weight | 8kg |
Max coil width | 200mm |
Cylindrical Vertical & Horizontal Adjustable Winding Mandrel
Vertical & horizontal dual-use cylindrical winding mandrel with variable diameter. Reduce changeover time and tooling costs for transformer and electromagnetic coils.
